Intelligent Barrier Gates With Telescopic Boom Max Length 5.9m

  • Intelligent Barrier Gates With Telescopic Boom Max Length 5.9m
สถานที่กำเนิด China
ชื่อแบรนด์ WONSUN
ได้รับการรับรอง CE, ISO, SGS
หมายเลขรุ่น WSTP-115
จำนวนสั่งซื้อขั้นต่ำ 1 ชิ้น
ราคา negotiation
รายละเอียดการบรรจุ Packed in bubble wrap firstly, and then reinforced with carton for outer packing.
เวลาการส่งมอบ 3-7 วันทำการหลังจากได้รับการชำระเงินแล้ว
เงื่อนไขการชำระเงิน T / T, Western Union, Money Gram, อาลีบาบาประกันการค้า, Paypal เป็นต้น
สามารถในการผลิต 1000 ชุด/เดือน

Contact me for free samples and coupons.

วอทส์แอพพ์:0086 18588475571

วีชัต: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
รายละเอียดสินค้า
Housing dimension 335 * 335 * 935 mm color Bule, Orange, White
Arm length Max. 6mtrs Product name Intelligent Barrier Gates With Telescopic Boom Max Length 5.9m
Housing material 2mm cold roller steel plate Arm length & height 100* 45 mm/ 80*45mm(swing out )
แสงสูง

automatic car park barriers

,

traffic barrier gate
ฝากข้อความ
รายละเอียดสินค้า

Bi-direction Intelligent Barrier Gates With Telescopic Boom Max Length 5.9m



Functions & Features

1) Manual release
2) Machine core with compression spring, effectively avoids the accidents caused by spring breaking
3) Die-casting aluminum alloy motor, precision and good at thermal radiating
4) Motor cooling fan, solving the problem of heat-protection
5) Double safety limit switches (photocell electrical limit switch/motor memory sensor)
6) Reversing on obstacle
7) Auto-closing
8) Support the INFRARER PHTOCELL for anti-bumping function (optional)
9) Support the external and internal VEHICLE LOOP DETECTOR (optional)
10) Traffic light interface
11) Wire control (switch signal)/ Remote control (418MHZ)
12) RS485 communication module (optional)





Basic Features:
1. By-security. The barrier gate will automatically go back when meet obstacles during closing.
2. AC motor is more powerful and no maintenance.
3. Barrier Beam/arm can be chosen from 3 meters to 6 meters, and barrier gate
4. closing time is also arranged from 1 second to 6 seconds.
5. The barrier gate can be both right-installed and left-installed.
6. All the operation process is soft without any noise and shaking.
7. Infrared photocell interface, Loop detector interface and IC system
8. interface are reserved for the other functions.
9. Green light and red light are used inside for indication the position of the beam.




Specifications:



Working temperature -40°C to +75°C
Power supply 220V±10% / 110V±10%
Rated power 120W
Opening time 1s, 3s, and 6s
Net weight

55KGS





Model Selection and Differences


Model

Boom Shape

Max Boom Length

Speed
WST-115 Straight arm 3M 1S

WST11561

180 degree, Articulated boom

5m

6 seconds

WST11562

180 degree, Articulated boom

3m

3 seconds










Technology Data:


Model

WSTP115

Working Temperature

-40℃～+75℃

Voltage

220V±10%, 110V±10%, 50/60HZ

Rated power

80W

Relative humidity

≤90%

Remote control distance

≥30m

Net weight

48kgs

Speed

1S,1.8S,3S, 6S

Max boom length

6 meters

Motor Rotational speed

1400rmp

Protection Degree

IP44



Service Items

1.One year's free servicing is supplied( not including the arm)
2. Lifetiom charged servicing is offered.
3. Technology servicing is supplied
The following situations are charged for servicing (or changing):
1. Broken by wrong installation.
2 Broken by improper voltae.
3. The surfaces of the system destroyed by wrong installation our use.
4. Broken by natural disaster.
5. Overdue
6. Servicing items out of our promises.
The upgrade and improvement of the product won't be notified if there is any.
The explaining  authority of this product instruction and service article belong to the production factory.



Communication with customers

1)   Q: Motor running but automatic barrier gate arm no action?

A

Reason

Solution

1

Barrier arm at 45° position where is hard to move

Unlock clutch and manually rotate arm to horizontal or vertical position then try again

2

Tension of balancing spring not suitable

Adjust spring exactly

3

Low working voltage

Check the voltage and power
